Sophos Xg Os



Sophos Central provides powerful centralized management, reporting, and zero-touch deployment for all your XG Firewalls and other Sophos products from a single console. Sophos Central is the ultimate cloud-management platform - for all your Sophos products. It makes day-to-day setup, management, and reporting for all your XG Firewalls easy. XG Firewall identifies hidden risks and threats that other firewalls miss and automatically isolates active threats - something no other firewall can do. Blocks unknown threats with a comprehensive suite of advanced protection including IPS, ATP, Sandboxing, Dual AV, Web and App Control, Anti-phishing, a full-featured Web Application Firewall. You can reimage XG Firewall with any firmware version. Use a bootable USB flash drive and reimage the device. Download and burn an ISO image to a bootable USB. Once you have migrated, at renewal time, you should purchase Sophos XG Firewall subscriptions and not the one you would normally purchase for Cyberoam OS or Sophos UTM OS – it will not work. When migrating, all initial licensing operations need to be conducted starting from the WebAdmin application on the appliance and not from MySophos.

You can reimage hardware, virtual, and software appliances.

Introduction

You use a bootable USB flash drive to reimage the device.

Caution Reimaging deletes all the data on XG Firewall. Save a recent configuration backup.

Reimage XG Firewall

You can reimage XG Firewall with any firmware version.

Use a bootable USB flash drive and reimage the device.
  1. Download and burn an ISO image to a bootable USB flash drive.
    1. Go to Sophos Licensing Portal and sign in.
    2. Go to Network Protection > Download Installers and select the required hardware, virtual, or software installer.
    3. Download balenaEtcher, a free tool to create a bootable USB flash drive.
    4. Run balenaEtcher and accept the license agreement.
    5. Insert a USB flash drive in your endpoint device. Select the firmware image you downloaded.
      Note The USB flash drive will be formatted. You'll lose all data on it.
    6. Click Flash and wait for the tool to create a flash drive that can restart the firewall, and wait for validation.
  2. To reimage XG Firewall, do the following:
    1. Power off XG Firewall.
    2. Optional To monitor the installation, connect an SVGA monitor to the SVGA port of XG Firewall.

      If it doesn't have an SVGA port, use an LCD panel to monitor the installation.

    3. Insert the bootable USB flash drive you created in XG Firewall.
    4. Power on XG Firewall.
    5. To enter the BIOS, press the Delete key when XG Firewall is starting. Make sure USB Key is the first boot option in the BIOS.
    6. Save and exit the BIOS.

      The firewall restarts.

    7. Sophos Firmware Installer starts reimaging XG Firewall.
    8. Monitor the installation.
    9. After the firmware is installed, remove the USB flash disk and type y to restart XG Firewall.
    10. XG Firewall restarts with the default configuration.
    11. Sign in and restore the configuration you want.
Sophos xg firewalls

Our XG Series hardware appliances are purpose-built with the latest multi-core Intel technology, generous RAM provisioning, and solid-state storage. Whether you’re protecting a small business or a large datacenter, you’re getting industry leading price:performance, and the ultimate in flexibility, connectivity and reliability in every form factor.

Desktop Models


Performance and connectivity for branch offices, retail and small businesses.

Sophos XG 85 / 85 Wireless
Rev.3

  • Firewall: 3 GBPS
  • NGFW: 310 MBPS
  • VPN: 225 MBPS
  • IPS: 580 MBPS
  • AV (proxy): 360 MBPS

Sophos XG 86 / 86 Wireless
Rev.1 - New!

  • Firewall: 3.1 GBPS
  • NGFW: 350 MBPS
  • VPN: 225 MBPS
  • Threat Protection: 145 MBPS
  • Xtream SSL: 75 MBPS

Sophos XG 105 / 105 Wireless
Rev.3

Sophos Xg Ospf Setup

  • Firewall: 3.5 GBPS
  • NGFW: 400 MBPS
  • VPN: 360 MBPS
  • IPS: 970 MBPS
  • AV (proxy): 150 MBPS

Sophos XG 106 / 106 Wireless
Rev.1 - New!

  • Firewall: 3.55 GBPS
  • NGFW: 400 MBPS
  • VPN: 330 MBPS
  • Threat Protection: 150 MBPS
  • Xtream SSL: 75 MBPS

Sophos XG 115 / 115 Wireless
Rev.3

Sophos Xg Os
  • Firewall: 4 GBPS
  • NGFW: 1000 MBPS
  • VPN: 560 MBPS
  • Threat Protection: 375 MBPS
  • Xtream SSL: 130 MBPS

Sophos XG 125 / 125 Wireless
Rev.3

  • Firewall: 7.0 GBPS
  • NGFW: 1275 MBPS
  • VPN: 1500 MBPS
  • Threat Protection: 400 MBPS
  • Xtream SSL: 170 MBPS

Sophos XG 135 / 135 Wireless
Rev.3

  • Firewall: 7.5 GBPS
  • NGFW: 1800 MBPS
  • VPN: 1700 MBPS
  • Threat Protection: 600 MBPS
  • Xtream SSL: 210 MBPS

1U Mid-range Models


Flexibility to adapt to the needs of mid-sized and distributed organizations.

Sophos XG 210
Rev.3

  • Firewall: 29 GBPS
  • NGFW: 3.2 GBPS
  • VPN: 1.92 GBPS
  • Threat Protection: 800 MBPS
  • Xtream SSL: 230 MBPS

Sophos XG 230
Rev.2

  • Firewall: 32 GBPS
  • NGFW: 4.5 GBPS
  • VPN: 2.1 GBPS
  • Threat Protection: 1000 MBPS
  • Xtream SSL: 280 MBPS

Sophos XG 310
Rev.2

  • Firewall: 35 GBPS
  • NGFW: 5.3 GBPS
  • VPN: 3.05 GBPS
  • Threat Protection: 1.55 GBPS
  • Xtream SSL: 370 MBPS

Sophos XG 330
Rev.2

  • Firewall: 38 GBPS
  • NGFW: 9.3 GBPS
  • VPN: 3.94 GBPS
  • Threat Protection: 2.1 GBPS
  • Xtream SSL: 560 MBPS

Sophos XG 430
Rev.2

  • Firewall: 55 GBPS
  • NGFW: 10 GBPS
  • VPN: 5 GBPS
  • Threat Protection: 2.2 GBPS
  • Xtream SSL: 600 MBPS

Sophos XG 450
Rev.2

  • Firewall: 65 GBPS
  • NGFW: 13.9 GBPS
  • VPN: 6.1 GBPS
  • Threat Protection: 3.4 GBPS
  • Xtream SSL: 770 MBPS

2U High-end Models


Optimal performance and redundancy for the distributed enterprise.

Sophos XG 550
Rev.2

  • Firewall: 75 GBPS
  • NGFW: 15.3 GBPS
  • VPN: 8.5 GBPS
  • Threat Protection: 6 GBPS
  • Xtream SSL: 1 GBPS

Sophos XG 650
Rev.2

  • Firewall: 85 GBPS
  • NGFW: 18 GBPS
  • VPN: 9 GBPS
  • Threat Protection: 7.7 GBPS
  • Xtream SSL: 1.35 GBPS

Sophos XG 750
Rev.2

  • Firewall: 100 GBPS
  • NGFW: 19.2 GBPS
  • VPN: 12.5 GBPS
  • Threat Protection: 9.4 GBPS
  • Xtream SSL: 1.4 GBPS

Software Installers


Sophos XG Firewall is also available as a software installer for Intel x86 and Virtual environments including VMware, Hyper-V, KVM, and Citrix


  • Sophos SF SW/Virtual Appliance - Unlimited Cores & Unlimited GB RAM

Sophos Xg License Guide


Sophos XG Firewall Features

See it. Stop it. Secure it.

Our comprehensive next-generation firewall protection has been built to expose hidden risks, block both known and unknown threats, and automatically respond to incidents.


Expose Hidden Risks

Superior visibility into risky activity, suspicious traffic, and advanced threats helps you regain control of your network.


Stop Unknown Threats

Powerful next-gen protection technologies like deep learning and intrusion prevention keep your organization secure.


Isolate Infected Systems

Automatic threat response instantly identifies and isolates compromised systems on your network to stop threats from spreading.

Secure Remote Workers

XG Firewall makes it easy to extend your secure network to employees anywhere.


Free, Easy-to-Use VPN Client

Sophos Connect provides an intuitive VPN connection client that’s easy to deploy and configure. Give your remote workers secure access to resources on the corporate network from Windows and macOS devices.

SOHO Protection with XG 86 or SD-RED

Our small, ultra-affordable XG 86(w) and SD-RED devices provide the ultimate in SOHO protection with always-on dedicated or split-tunnel VPN that’s easy to deploy and manage with a variety of flexible options.

Mobile VPN

Mobile devices can utilize built-in or app-based VPN options including IPSec and SSL VPN for secure connectivity to your XG Firewall protected network.


XG Firewall’s all-new Xstream architecture delivers extreme levels of visibility, protection, and performance.

XG Firewall Xstream TLS Inspection

Industry-leading performance and visibility into all the encrypted traffic on your network with support for TLS 1.3

XG Firewall Xstream DPI Engine

High-performance deep packet protection in a single streaming engine for stopping all known and unknown threats

XG Firewall Xstream Network Flow FastPath

Accelerate trusted and important cloud, SaaS, and VoIP application traffic for optimal performance

A Firewall That Thinks Like You

We’ve rethought the way firewall rules and security policies are managed. Sophos XG implements a refreshing new unified approach to network security that enables you to see and manage all of your protection in one place – the Rule and Policies Screen.


Policy Perfection

Utilize dozens of built-in protection policies for IPS, web, traffic shaping, and more or quickly customize or create your own policies.

Sophos xg firewalls

Visual Policies

Protection policies snap-in to firewall rules enabling you to immediately see all the protection being applied to any given source/destination, user/group, or traffic type.

Firewall Flexibility

Granular options for TLS inspection, NAT, and SD-WAN routing enable XG Firewall to fit any network rather than forcing your network fit the firewall.
